Sand questions 11/11/08 Greetings from Singapore! <Hello!
Jessy here. Greetings from southern California!> Got a quick question
for u. I have a 11 month old 3ft, 60gal, FOWLR tank with some grade '0'
sand(around 1" deep). Since my wavemaker pump keep pushing my sand away
to the side(leaving a huge gap in the middle of my tank), I decided to
add more grade '0' sand to make it deeper(around 4" deep). Will it be
causing any problem to my Livestock/Tank? <Adding new sand shouldn't
cause any issues to your livestock, if it was new sand. You could
possibly have a small ammonia spike if there was anything in the sand
that would die off, but generally speaking you should be safe. As a
precaution I'd keep an eye on your levels and water changes are always a
great way to prevent any unforeseen disaster.> Thanks, Andrew
Munday <Regards, Jessy>
DSB question and more 6/16/08 Hi.. <Hello Mohamed!>
Better to give you details on my reef aquarium.. I have a 90
gallon aquarium with a 25 gallon sump, OR1200 return pump, AquaC
EV180 skimmer, 1 Tunze stream 6060, 2x 150w 14k Metal halides, 4x54w
Aquamedic actinic T5 lamps and 2x54w T5 white 10k lamps. <Sounds
like a great setup.> I have a 4.5inch DSB with no plenum. Is this
okay??? <Yes, definitely.> Secondly, my sand bed is very dirty
most of the time... what should I do to remedy this? Will more flow
help?? <More flow is one of the primary tools to keep the sand
from accumulating detritus. Small sand stirrers such as Nassarius
snails can be helpful too. If your sand is dirty with algae or BGA,
that is another issue.> How’s the algae free sure flow mod for
the Maxijet 1200?? <It is great, I love them. I was part of the
pack the last few years fabricating my own, the new drop in kits are
lifesavers. Low power draw, quiet and tons of flow.> Furthermore,
the sand I use is very fine... about 0.5mm or less. It is about 2
years old. Due to this, a lot of sand keeps blowing in my tank and
it always goes on top of rocks and stuff no matter where I point the
Tunze. I’m going insane trying to control it even without the Tunze.
<It will take a bit of trial and error to get it right, but it can
be done. You will likely find it easier to keep your sandbed in
place throughout most of the tank with the addition of another
powerhead (such as the MJ mod). Colliding the flow from the two can
provide a greater, but more dissipated flow. With one the
directional flow can be tough, digging troughs that other sand then
falls into, continuing the cycle.> Note: Tunze is on the back top
right corner of my 48"x24"x18" tank and is pointing straight to the
other end (length wise). Should I use a coarser grain of sand to
avoid this problem?(2-3mm).. If so, how do I do it in an established
aquarium? <You can if you wish. I personally like the sugar fine
sand. If you do want to switch you can siphon out the sand with your
water changes over a period of a few weeks, then replace with the
new. One word of warning: if your rocks are supported by the sand
you will end up with a rockslide. If this is the case you may have
to teardown the system to switch. Again, the fine stuff can work
with some experimentation with flow.> Also, I got Caribsea
Aragamilk and have been using it for 3 weeks and my calcium is still
300-320ppm.. I stopped using Kalk due to pH fluctuations. Also
on your recommendation, I have purchased a Milwaukee ph controller
and GEO 618 calcium reactor to remedy this but the shipment has not
yet arrived (will do so in a week). Will the reactor be able to pull
the calcium up to the 400s? <It can, but with an increase in
alkalinity too. You will want your Ca and Alk in balance, then use
the reactor to keep it that way.> Is there anything DIY I can do
in the meantime? <For the amount of time you are looking at you
will want to simply buy a small quantity of another Ca supplement or
increase your water changes to get things in balance, assuming your
salt has a higher level of Ca (it should). > Thanks a bunch and I
hope you guys can help me make my tank look good... PS: how’s the
blue background at the back of the tank? Should I change it?
<Looks good if you like blue backgrounds ? A personal choice that
will be covered in coralline with time!> Mohamed. <Welcome,
thank you for writing, Scott V.> |   |
RDSB Water Flow Questions 12/21/2007 WWM Crew, I just finally
finished reading the many pages of information on deep sand beds and
nitrate reducing methods. I found it to be an excellent discussion and a
wealth of information. However, I have a question that remains
unanswered... For background, I have a new 210G BB SPS dominated tank
with a 60G sump, and I'm using a 75G AGA (48" x 18") for a RDSB with 6"
of sugar size sand. The RDSB is not lighted. I have 150# of Tonga LR in
the main display. I'm using a Reeflo 250 Orca as my skimmer and I
typically run carbon passively in my sump. Flow through the entire
system is high with detritus staying in suspension and being removed via
a filter sock in the sump. My main focus/desire for the RDSB is for
nitrate reduction followed by an increase in bio-diversity of the
overall system. I'm interested in opinions on both (1) overall flow
through my RDSB as plumbed into my total system (currently I'm moving
less than 200G/hour through the RDSB tank with the returns directed at
the top of the tank) <This sounds good to me. I'm sure opinions vary
on this, but I think as long as your moving about as much water in an
hour as you have in the main tank, you're probably good. Of course, to a
point, more is probably better.> and (2) flow within the RDSB, not
only in volume, but with respect to how, where, and by what means
(currently I have no additional flow other than the main returns).
<Water flow actually THROUGH the DSB is largely dependent on the benthic
life of the sandbed. You want to have a lot of worms, micro-crustaceans,
etc. living in the sand to turn the sand grains around. This is what
moves water down and through the sand.> Specifically, I'm interested
in opinions on flow techniques at the sand/ water interface level.
<If you want to add more water flow above the sand bed, you can just add
a powerhead. If you don't think you can do this without creating a sand
storm, you could try piling some rocks in one corner and pointing the
powerhead at the rocks from the other side of the tank.> Thanks in
advance and thanks for maintaining this excellent resource. Tony
<De nada, Sara M.>
Exciting new question... same old DSB questions – 09/13/07
Hello.. (sorry for subject line, just trying to inject some excitement
as i know you must get flooded with the same questions) Compliments
on a great site, so much information, and it seems, a complete
information overload for my brain. My husband and I have been in this
hobby for 9 months and have fallen in love with it to such a degree that
we have just upgraded from a 42 gallon (UK) to a 130 gallon. (30 gallon
sump) inhabitants will be fish (yep!) LR, inverts. The old tank had 1/2
inch crushed coral sand this has now gone. We fully intended to go
with a DSB for this new tank as we were under the impression this is the
best way to go, our LFS (bless them) said not to, as it can release
sulphur back into the system which will kill all livestock? <Ugh...
this is just not true.> Obviously we want to set this tank up right,
from the start. In your humble opinion, should we go for a DSB in the
main tank (4 + inches of aragonite, live sand or normal?) <Sand beds
are great for keeping nitrates low and adding biodiversity to the tank.
Fine aragonite is preferred, but pure silicate sand-box or masonry sand
will do just fine. But whatever type of sand you end up getting, you'll
need to "seed" it with live sand and live rock. Please start here:
http://www.wetwebmedia.com/deepsandbeds.htm and try here:
http://www.reefkeeping.com/issues/2003-06/rs/feature/index.php and do
a search on WWM and/or Google for deep sand beds. There's a whole lot
out there written on this topic.> should we also have a DSB in the
sump? <If you have one in the display, you don't need one in the
sump. But it's up to you.> or shall we go with Miracle mud?
<Miracle mud is not necessarily any better than any other type of fine,
live sand.> I assume we would need sand sifters of some description
as well. <You need worms and other critters, but not sand sifter
stars (or other such echinoderms which can actually destroy sand beds).
Again... do some research. There's a lot out there to read.> As there
is so much information, pro's and con's, it can be confusing and I guess
it's personal taste but any advice would be greatly received. <Do a
lot of reading. This is the only real advice I can give you here. Don't
just go by what the LFS tells you (and that applies to just about
everything).> Thank you in advance, Nicola <De nada, Sara
M.> New Tank
Question: DSB and Water Movement
7/30/07 Hi James, How is everything? Hope everything is well.
<Hi Jon, everything fine here.> Before anything else, I am happy to
tell you about the Fromia millepora (red sea star) that I have inquired
about. I was so happy when I finally moved him from my quarantine tank
to the display tank. He immediately went around and took some algae I
left for him in the front of the glass. He's been all over the tank
already and for two days now seems doing just fine. I love him and did
add diversity in the tank. <Good to hear.> James, you have seen
pictures of my tank and it is indeed very healthy as you have mentioned.
I probably have over 50 baby snails by now crawling about the tank
thanks the initial 10 Cerith snails that kept laying eggs. Moreover,
just tonight, I believe I saw the eggs of my 2 clown fish. I feel it is
their egg as they were protecting it unlike the eggs laid by my Cerith
snails that they very much like to nip. Oh boy, it’s been truly a
wonderful experience for me. Love every minute of it. <Can be a
rewarding hobby.> The sponge that has grown at the back of my LR is
now protruding upwards and has covered the top of this rock and is
exposed to total light. It is quite interesting to note that the color
on this one however is orange yellow. At its current growth rate, I may
not have room for new corals at all. As you know James, this is my
1st venture in having an aquarium and a SW tank at that. I really could
have not done it with your help. <Glad to be of assistance.> Old
tank questions (60 gal): 1st. I have been setting my eye on some
Holothuria cucumbers (particularly the tiger tail). I prefer them over
the sand sifting star (which I read devours everything in the sand).
<Anything dead, yes.> The thing is for weeks now, since I last wrote
you, I have wanted to add more diversity for my current tank. I am not
satisfied yet with the research I have done on it so far. There is
simply too much variability for me to make any realistic generalizations
about the risk of this specific sea cucumber. The best generalization
that I can make is that for most deposit-feeding sand cucumbers the risk
of a tank wipe-out is quite low and considering the added benefit plus
bio-diversity in my tank, I am beginning to feel it is worth a try. Am I
right in thinking this? (My first question). Secondly, if I am to put it
1st in my quarantine tank for 1 month, how am I to feed it? Lastly, how
do one properly acclimate this? Is it the same as your advice to me as
the red sea star? <Jon, I'd stay away from cukes, they can be more
trouble than they are worth. Read here if you haven't already.
http://www.wetwebmedia.com/seacukes.htm The sand sifting starfish would
be a much better choice. Keep in mind, these guys should be fed
unless you have a well established sand bed. I feed mine with a syringe
(no needle attached). I take the syringe and draw up a few bloodworms
and inject them under the starfish. Has been working well so far. They
will also eat dried Nori.> 2nd. I know Phosphate less 0.03
concentrations is a good value for reef aquaria. Last week, I purchased
a Red Sea P04 test kit and for the 1st time have tested P04
concentration in my tank and found out that I have about 0.1 ppm PO4
level. <More than likely you are just reading the low end of the
scale and is not indicative of the actual level. Phosphates are
generally absorbed in the system very quickly.> I am not having
hair algae nor some red slime outbreak or anything but want to make sure
I won’t have them at all (I do have some hair algae but is controlled in
just one spot and comes and goes). I have a refugium with lots of
Chaetomorpha algae that I trim from time to time which I believe helps
(thanks to your advice early on). Does putting some ROWAphos or PhosBan
in a poly filter bag and hang this by the sump do the trick? Or is it
really necessary to get a Phosphate reactor as some other guys in other
websites seems to strongly suggest for some fluidize action. I ask
because everything seems fine…”Now” but I don’t know why I keep worrying
about something that has not happened yet. Also I feel I don’t really
want an absolute zero PO4 at all because my current tank seems to be
thriving (I have maiden’s hair and shaving bush plants in the main
display tank and some spaghetti algae in the refugium). <I'd leave
well enough alone, but if I decided to use a product, it would be
Rowaphos.> New Tank (2009 7’x3.5x2’ Upgrade tank) 1st question.
Given the size of the tank, if you were me, how big/ proper ratio should
the refugium be if I were to use DSB on it? How deep of a DSB would you
go? Will you employ the use of a plenum (mix opinion on its usage -
quite confusing)? Main tank will have at most 2 inch of live sand. I ask
this because I read somewhere here or maybe Mr. Anthony Calfo's book (I
can't remember) that a refugium size 20% of the display size is
recommended for effective NNR. I also remember reading here a long time
ago that a small amount of nitrates is beneficial or even necessary for
keeping corals and to target 1-5ppm. <Jon, do search/read on our site
on DSB's and refugiums. There is too much info available for me to write
here. Yes, small amounts of nitrates are beneficial for plant/algae
growth, and clams will also absorb it.> 2nd question. Again if you
were me, what system would you use with regards to water circulation and
proper water flow if you want to keep mostly SPS with a few LPS and soft
corals? This tank is going to be in the center of the room viewable on
all sides with pipes running to a room (about 15 feet away, piping under
the floor boards) for the stuffs needed to keep the tank thriving.
Obviously, the overflow is going to be in the center of the tank which
is why I am having quite a fascinating imagination of how I am going to
properly move the water. I want to eliminate as much as possible using
powerheads attached to the glass. <I'd bulkhead the water coming into
the tank and use a couple of the SCWD' (Switching Current Water
Director) in the system. Again, this subject should be searched on
our web site, too much info requiring too much time to do here. Go here.
http://www.wetwebmedia.com/plumbingmarart.htm One thing to consider in
planning is the distance from tank to pump. Every foot of pipe used
will lower the pressure/flow rate of the pump and the amount of water
that can be returned to the sump. Here is a link to some useful
information regarding this. http://www.reefcentral.com/calc/hlc2.php>
Lastly your thoughts on the best skimmer out there to blow waste off
this upgrade tank. I was thinking of Precision Marine Bullet XL Model 2
protein skimmer. My second choice is a Deltec Protein skimmer but they
are just way too expensive for me. <Personally, I like the AquaC's.
Virtually hassle free and very efficient.> Thank you so much again
James. It has been truly a joy writing you. <Why thank you, Jon, and
good luck in your new venture.> Sincerely, Jon G.
DSB, gen. – 07/03/07
Morning crew! I've come to bother you for some more advice... At
current I have a 55g tank with roughly 45-50lbs of live rock and nothing
filtration wise but a prefilter and a recirc skimmer in my sump. Being
as I've had my old 30 gallon tank glaring at me for some time now, I
though about adding in a refugium with a DSB for added
filtration/denitrification and fauna production for my dragonet. Is it
reasonable to try and add this after my tank has been setup? <Sure>
My plan was adding about 6" of fine to medium grade sand and a few
pieces of (cured from my show tank) live rock to get things started.
<And/or you should add about a measuring cup or two of your live sand
from your established tank.> Does a DSB have to be cycled and
functioning before I plumb it into my system? <That depends a bit on
what type of sand you'll be using. Aragonite sand can leach stuff (like
phosphates) when it's "new." So if you use aragonite sand, you might
want to "cycle" it for a little bit before attaching it to the main
tank. On the other hand, silica sand (masonry or classic sand box sand
-- i.e. the kind that makes glass) should be good to go after a good
rinsing with RO/DI water.> Or would I be fine to set it up and turn
it on with no ill effects? <See above. :-)> My second question is
on what inverts I should populate my refugium with for adequate sand
stirring? Unfortunately to date I've not found any information on the
subject that actually recommends anything specifically, simply "add sand
stirring inverts" but perhaps I've not looked hard enough? <Well, if
your current sand bed is well populated, then the answer is simple...
just use your old sand to "seed" your new sand. If not, try looking for
starter (or "seeder") live sand sold at a variety of places online (not
the stuff sold in bags, the stuff kept and cultured in tanks). The "live
sand" sold in bags is good stuff, but it's not likely to have much in
the way of critters (probably mostly just bacteria and some other
microbes). To get the good worms and everything, you'll need live sand
that's been cultured in a tank. Or, you could just bum some off a fellow
reefer with a well populated sand bed.> Thanks for the help, Mike
<De nada, Sara M.>
Another DSB/Nitrate Reduction Question – 06/23/07 I have a 58gal
tank + sump with approx 45lbs live rock, crushed coral substrate.
<<This last is likely a large contributor to your Nitrate issue>> A
Finger Leather, a few Mushrooms, Xenia, Zoanthids and some Yellow
Polyps. <<But for the Xenia, quite a noxious combination>> All are
small and well spread out. <<But in a relatively “small” volume of
water…do employ some purposeful chemical filtration
(Poly-Filter/Carbon)>> Livestock = Yellow Tang, <<Tank is not big
enough for this fish, mate>> Maroon Clown, Royal Gramma and a Sixline
Wrasse + Snails and Hermits. <<Not that you should consider it now,
but if things change, that Pseudocheilinus will make future fish
additions problematic>> Protein skimmer that makes about an 8-12oz of
dark skimmate a week. My nitrates are consistently in the 20s. <<Ah
yes, this needs to come down. It’s hard to say for sure but, perhaps you
need a better/more efficient skimmer>> 5-gal water change every 2
weeks with aged RO water. <<Allowing the salt mix to “blend” for
several days I hope>> It’s understood that by increasing water
changes, I will dilute the Nitrates, but I do not want to have to do
this on a permanent basis. <<Mmm, understand the mindset…but on this
small volume this is an inexpensive and most healthful process. And
doubling the volume to 10-gallons could make a very big difference
here>> Reduced feeding does not seem to help reduce the Nitrates.
<<Coming from somewhere else>> It seems that I have a lot of debris
in the crushed coral even after using a gravel vac. <<Course
substrates can be very problematic>> I have taken some crushed coral
out and cleaned it but I am afraid to do a lot at once for fear of
shocking the tank. <<Mmm…may not be much of an issue if the existing
depth/volume is small>> I think that a DSB is the way to go. <<I
am a strong proponent of this methodology>> After the DSB is up to
par I would add more live rock. <<Don’t act too quickly re the
rock…fishes need room to roam>> At the present, 100lbs of pet store
aragonite is not in my budget. <<The retail side of the hobby IS
proud of this stuff>> I see 4 ways to get to my goal of having a DSB.
1) Remove all of the crushed coral at once and add a bag at a time of
aragonite over several months until it reaches the 4-6 in. depth. 2) Add
a 12x16x4 DSB in the sump inside a plastic container and then do the
above. 3) Wait until I can get enough sand to do the change at one time.
4) Wildcard option, to use limestone play sand that I found in a local
Home Depot (Chicago region). It did pass the vinegar test, but it
does not say where it is from. The pallet is in a slot marked Old Castle
but I did not see Old Castle on the label, I can/will check again.
<<This is probably not Limestone but rather Aragonite sand…and most
desirable/useful as such re our hobby>> If these were your choices,
what you would do? <<Hmm, a combination of all these choices! I would
purchase sand from Home Depot…add the DSB to the sump and wait a
week…remove the crushed coral from the display and add the full depth of
sugar-fine Aragonite to create the DSB… And do consider rinsing this
sand before adding to the display. Some authors say this isn’t
necessary…and on new systems it is less of an issue…but I speak from
experience when I say you will not like the result if you merely dump
this sand in to your existing display without rinsing away at least
“some” of the “fines”>> Until the nitrates are lower, I will not add
anything and will have to increase the water changes. <<Good>> I
consult the WWM regularly and am thankful to all of the crew for the
comprehensive site. <<The “Crew” is happy you find the site useful>>
I do not understand how you all have the time and patience to answer our
repetitive questions. <<Hee-hee! Can be trying at times for sure…but
the greater good we “know” we are doing far outweighs the occasional
inconvenience or thoughtless/selfish querier. And to be fair, the “Crew”
has it easy compared to Bob who must “handle” all the queries we leave,
as well as maintain the site/post all for the public’s edification>>
After reading your daily questions for a while, I have come to the
conclusion that many of us who ask questions (myself included) are not
ready to accept the hard truth; we want a magical cure to Ich and other
problems, as in my case Nitrate reduction. <<Ah yes! Tis true many
write in looking for validation for something they know is wrong, and
subsequently refuse to accept the “hard truth” as you say…but by far the
majority of folks are just looking for some “personal”
attention/guidance to their dilemmas. And as we often tout here…nobody
should rely on a “single” source for their information anyway. Hobbyists
should research/attempt to gain information from a variety of sources
(books, NET chat forums, WWM, hobby clubs, etc.) and use their own good
judgment to choose a course of action…WWM is just one cog on the wheel>>
Thank you! <<Quite welcome…and “thank you” for this opportunity to
rant [grin]. Eric Russell>> DSB Size/Depth - 08/29/06
Hi again, <<Hello>> I am trying to add a DSB for my 125 FOWLR
due to a persistent nitrate problem. <<Ok>> I do have sand in
the main display at present but due to the home improvements done by my
fish on a regular basis the SB is 2-3" in some spots and much less in
most others. (Apparently they don't understand the benefits and keep
moving it around when I try to fix it.) <<Ha!...indeed>> Be that
as it may, how big of a sump/refugium and how deep of a SB would be an
appropriate remote DSB? <<In my opinion...As large a vessel as you
can practically employ, with a "minimum" 6-inches of sugar-fine
aragonite>> I also have close to 200lbs of LR in the system. Thanks
again for all your help. Mordy <<Regards, EricR>>
DSB/Wet-Dry/Nitrates - 08/28/06 Hi there! <<Hello!>> How
are you all today! <<Don't know about the rest, but I'm doing fine,
thank you>> I hope I am not bugging you with a repeat question.
<<No worries my friend>> I have read thru all your FAQs on sand beds
and am getting confused. <<Oh?>> There seems to be many
contradictions and I really want to get it right.
<<Indeed...differing methodologies/opinions...>> I have a 220 gallon
setup that is about 8 months old. I used 220 lbs of live rock to set it
up as well as about 120 pounds of CaribSea live sand. That gave about
an inch of sand on the bottom. <<Ok>> I also have a wet-dry
running and am not sure if this is necessary and will contribute to
higher nitrates. <<The wet-dry filter is not necessary, or even
desirous, if this is a reef system...but can be beneficial to a FOWLR,
though these days my preference when additional bio-filtration is needed
is to turn to a fluidized-bed filter>> My nitrates are around 50.
<<Mmm, you have a problem then, in my opinion. Nitrates should be <5ppm
for a reef and <20ppm for a FOWLR>> I have an ASM G3 protein skimmer
and a Blueline 40HDX pump. After the first few months of losing several
fish, my tank seems to be settled and I have had luck with my fish for
the last 4 months without any casualties. <<Won't last with nitrate
readings this high. Though maybe not immediately evident, the high
nitrate level will have/is having an effect on the fish and will cause
problems/deaths in the long-term>> I'd like to get my nitrates to 0
and am wondering if I should increase the sand bed to at least 4 inches
and get rid of the bio-balls. <<One approach>> I could also add
some more live rock. <<Sounds like you have a lot of rock in there
already>> Would you advise this or should I stick with my 1/2-1 inch
sand bed (I lose some sand every week when I vacuum as it's fine sand)?
<<I'm a fan of DSBs...I would try increasing the depth of the sand
bed...and stop the weekly vacuuming as this will be counterproductive to
the DSB. If detritus accumulation is a concern, then increase water
flow in the tank>> If I made it a DSB, how would I go about it with
all the fish and live rock in there? <<Considering the current
depth/weekly vacuuming, simply add the sand until you reach the new
desired depth. Pre-rinsing will help to reduce the associated
cloudiness>> Can I purchase a different kind and put it on top?
<<You can>> I would like to add some pink. <<Won't stay
"pink"...I recommend a sugar-fine substrate, though you can go a bit
larger if you wish (1mm-2mm)...or even go with a mix of these>>
Also, would the LR need to be removed if I was adding 3 or 4 more
inches? <<Nope...in fact, I prefer to place my live rock on the tank
bottom and fill around it with the sand for better stability>> What
about the fish? <<If you go to the trouble to pre-rinse the sand to
reduce the "fines" suspended in the water column they should be
fine. If you wish, you could even add the sand in stages (a day or two
apart)>> I really have no where else for them to go as it's a
220. Maybe knowing my fish would help determine what sand bed is best
for my tank. I have a Bluefaced angel, a maroon clown, a purple and
sailfin tang, a fairy wrasse, a Twinspot wrasse, a zebra moray and a few
gobies. Also 2 anemones and a couple starfish and hermit crabs.
<<Yikes! Anemones and 50ppm nitrates? Maybe you should try testing
with another brand of test kit (Salifert, Seachem) to validate this
reading>> I have had a little trouble with red Cyanobacteria and
have been physically suctioning it out every week as well as weekly
water changes. I can't get it all off the rock but do blow some of it
off with a bulb syringe. I was wondering if increasing the sand bed
would help get rid of that as well as hair algae which I have a little
of? <<The DSB will provide numerous benefits, one of which will be
the reduction of nitrogenous compounds (algae fuels), but an increase in
water circulation will also help with the Cyano>> Any help in
resolving the sand bed issue once and for all for my setup would be
greatly appreciated. <<I think a 4"-6" sugar-fine DSB to be a
worthwhile addition. As for the wet-dry, you might try replacing the
bio-balls with fist-sized pieces of live rock and see if that helps with
your nitrate. Adding some carbon/Poly-Filter somewhere in the filter
path will also prove beneficial>> I want to do the best I can for my
fish and make it as healthy in there as I can for them. <<Then
address/determine the source of nitrate and bring that reading down. Do
have a look here and among the links in blue at the top of the page: http://www.wetwebmedia.com/nitratesmar.htm
>> You have such an awesome website and I read it often. <<Were
pleased you find it of use>> Thanks so much for all your help.
Heather <<Happy to assist. Regards, EricR>> Re:
DSB/Wet-Dry/Nitrates - 08/31/06 Thanks Eric for all your great
advice so far. <<Is my pleasure>> I did add a Poly-Filter.
<<Always beneficial>> I change my carbon monthly and I clean out my
filter pad as well as protein skimmer at least every other day.
<<Excellent>> I was all set to order 150 pounds or so of sand when I
decided first to take your advice and try another nitrate testing kit.
<<A good move...and the cheaper route no doubt>> I bought the one
the LFS had which was SeaTest and got a reading of 10 or less while the
Red Sea by Marine Lab reads at least 50. <<Mmm...>> How can
there be such a discrepancy? <<Many reasons my friend...differences
in quality/age of reagents, contamination, inaccuracy of the
gauge/scale/benchmark...even human error <grin> >> It seems odd that
two tests can be so far apart. <<Is advisable to keep fresh test
kits of good quality (Hach, LaMotte, Salifert, or Seachem...to name some
of the better ones available)>> It makes me angry after spending so
much money on my setup and continually trying to find ways to bring
my supposedly high nitrates down. Which test should I believe?
<<I'm inclined to believe the SeaTest over the Red Sea kit>> I
prefer my shallow sand bed and would rather not add 4-inches or more to
it if my nitrates are under control. <<Indeed, maybe you don't need
the extra denitrification the DSB would offer after all>> I plan on
this being mostly fish therefore the bioload will be higher than a reef
tank and I worry that in the long run the DSB might not be best for
a FOWLR tank. <<The DSB would be fine...though a fluidized-bed
filter will react more quickly to fluctuating bioloads and is likely
cheaper and easier to install>> I will remove the bioballs and put
LR in the wet/dry like you suggested. I appreciate all your help.
<<Happy to assist>> I now have a dumb newbie question. <<Ok>>
You mentioned that I might want to increase the flow to my tank.
<<Yes>> My 220 has two overflow boxes predrilled and I have a
Blueline 40HDX pump which I was told was more than sufficient for my
tank. <<Mmm, about 1200 gph "before" head loss..."sufficient" for
feeding the sump yes, but not likely to provide "sufficient"
flow/elimination of dead-spots/suspension of detritus...in my opinion>>
However I don't think it pumps your recommended 10-20 times per gallons.
<<Likely not even 5x your tank volume, after head loss>> How would I
add more flow to this system without it looking ugly? <<Perhaps
addition of a couple Tunze Stream pumps, or a "closed-loop" with a
multi-nozzle return manifold (see here and the links in blue:
http://www.wetwebmedia.com/pbretfaq3.htm and http://www.wetwebmedia.com/circmarart.htm
>> I know this is a stupid question and probably very basic but I'm
not really sure how to go about increasing the flow. <<Not stupid,
and not always "basic", but do read the link/links provided and
learn/choose your options. Get some ideas of what you want to do and
come back to bounce them off me if you wish>> I do have a deep tank
at 30 inches and some Cyano on the sand. It is also only 8 months old
and I don't know if this is a phase or something I should address?
<<If your only source of water flow is your sump return, increased water
circulation may indeed help>> Thanks for all your great advice.
<<Always welcome>> I don't trust my LFS very much because when I
told them I thought my nitrates were around 50 they said I was crazy to
worry as their fish only setups have nitrates of over 300. <<Mmm,
well...while it's true that in most FO/FOWLR systems Nitrates "alone"
may be no real worry, 300ppm will certainly cause harm. The fact this
store claims no ill effect is largely due to the "transient" nature of
the livestock ...though their customers are likely not so lucky do to
the harm/further insult to health imposed by this store on their
livestock with this kind of water quality. In my opinion, it is
irresponsible (and probably just plain laziness/ignorance) to subject
the livestock to these nitrate levels no matter how long the duration,
and even more irresponsible to advise customers that this is "OK">>
They seem to think I'm a bit crazy and that I overreact and worry too
much about my fish. << (sigh) Maybe it's time to find another
LFS...>> That is why and how I found your site and am a true fan.
<<Yay!>> Thanks! Heather <<Be chatting, Eric Russell>> Re:
DSB/Wet-Dry/Nitrates - 09/01/06 Hi Eric! <<Hello Heather!>>
I think I'm becoming your groupie. <<Hee-hee! Cool, I think you're
my first!>> Thanks so much for your speedy reply. I was shocked how
fast you wrote back. <<A matter of timing/luck for the most part>>
And it's nice to converse with someone who cares about this hobby and
doesn't roll their eyes at me when I ask too many questions. <<Mmm,
indeed...too bad your LFS doesn't see the value in education/keeping
their customers in the hobby...or maybe they just don't have the
capacity re>> (Well maybe you are but I can't see it at least like
at my LFS) <<Ha! I'll never tell! (and spoil my image <grin>)>>
I've been reading and am considering the Tunze Turbelle Stream pump.
<<An excellent choice...I use these for water movement in my own
system>> It's around $190. <<Not cheap, but excellent
quality/engineering/performance>> Is it all inclusive or do I need
to buy anything else with it? <<Based on the price I'm guessing
you're looking at the model 6080? This is a synchronous-motor pump
(does not run on a controller/wavemaker) and is ready to go out of the
box. But, depending on your tank design/bracing, you may need one of
the holding device extensions (3000.244 or 3000.260). These should be
available on the site where you purchase the pump (if not, they can be
found at MarineDepot.com), just review the information on each and
determine which is needed (if any) for your tank>> The internet
stores don't really say much but they talked about timers and wave
controllers. Is any of that necessary? <<No...and not possible with
some pumps/powerheads>> Where is the best place to put it in the
aquarium? <<Hmm...distal from the sump return line...and positioned
toward same for creation of a random turbulent flow pattern>> Would
one be good since it says it pumps about 2250 gph on top of my 1200 gph
I'm already getting? <<If this creates enough water movement to keep
detritus in suspension/eliminate dead spots, yes...will likely take a
bit of experimentation to determine the optimum position (or number of
powerheads required)>> I have a feeling that more gph would
definitely help with the Cyano. <<Me too, though other factors to
consider as well. Have you read our articles/FAQs on blue-green
alga? Here's a good place to start:
http://www.wetwebmedia.com/bluegralgae.htm>> I always worried 5X
wasn't enough flow but again my LFS disagreed with me. <<You must
evaluate the needs/requirements of the livestock, but it is likely an
increase in flow will be appreciated...even "enjoyed">> I'm trying
to find another LFS but I live in Melbourne Beach Florida and unless I
want to drive 90 minutes there are only 2 close by. I'm not too happy
with either. <<I see...best to arm yourself with "your own"
knowledge/research>> You were right about the 300 ppm nitrates
hurting fish. When I sat down and worked out where all my fish losses
were from, they were all from that store. <<Indeed...as if the
stresses of capture/transport weren't enough already...>> I think I
lost 8 out of 10 of the fish purchased there for a loss of about $500.
<<a pity>> All my other fish purchased elsewhere have done fine.
<<Hardly a scientific analysis...but does seem rather telling>> I
guess they only care about the bottom line. <<Unfortunately there
are stores out there with kind of short-sightedness>> Neither store
carries live rock and the store that did and had a conscientious owner
(shocking), went out of business. <<...why does it always have to be
the good one's...?>> Do you recommend any internet sites for quality
cured rock? <<Some of the members of my local reef club have been
raving lately about the rock offered at Reefermadness.us >> I guess
that is it for now. I'd like to purchase a quality pump that gives good
gph and add some more LR and see how that goes. <<Sounds fine>>
I read the links you sent me as well as Anthony's report on pumps and
like the Tunze like you suggested. <<You won't be disappointed>>
Thanks so much! Heather <<Cheers my friend, Eric Russell>>
DSBs...Bed Size/Sand Type/Depth 8/12/06 What's
happening? <<Good Morning!>> I just got my brand new 135 gallon
(72x18X25) glass aquarium the other day (got a good deal at
Glasscages.com, in case some one needs a recommendation on an
inexpensive source) and am planning on setting up a new reef.
<<Cool!>> I want to use my old 55 gallon that I have now for the
refugium. <<A great idea>> I have been doing a bit of reading
about the proper depth of the sand bed and came to the conclusion that
is should be 1/2 inch and no more or 4-6 inches and no less.
<<Depending on what you want from it/what you want it to do, yes...a
good "generalization">> I wanted to run my plan by you guys (and
ladies) and get an expert's opinion. <<Have never considered myself
an "expert", but I'll be glad to share my opinions/experiences>>
Because I don't care for the looks of 6-inches of substrate and aren't
looking forward to spending hundreds on sand, I plan on only using 1/2
inch of sugar fine aragonite in the display and packing the 55 gallon
refugium with 6+ -inches of slightly coarser aragonite to get the
benefit of the DSB. What do you think? <<This sounds fine and is a
quite acceptable alternative to placing the DSB in the display
tank...though the total surface area will be quite less, as your are
aware I'm sure>> I'm assuming once I install the baffles I will have
about 30" of the original 48" of space in the refugium to cover with the
substrate. Will this be substantially large enough to do the job, or is
the 6-inches in the display needed as well? <<All relative...the DSB
in the refugium will be effective...just not as effective as a larger
DSB in the display. Whether or not it is effective enough will depend
largely on the stocking density of the display and your aquarium
maintenance habits/husbandry skills>> Will adding more than 6-inches
in the refugium be even more beneficial or would it be overkill?
<<Depending on the coarseness of the substrate you use, a few additional
inches could be beneficial>> From what I read it sounds like DSBs
need more flow to keep nutrients from building up. <<A healthy flow
rate does help, yes>> Would you recommend an under gravel filter
with some powerheads, or just a strong pump circulating the water from
the refugium to the display? <<Definitely the latter>> I also
wanted to ask what you thought about oolitic sand? <<Is ideal for
marine sand beds/DSBs>> I saw an ad on EBay with decent prices. All
it says is that it is oolitic, .4mm-1.6mm, consists of aragonite,
dolomite, calcite, crushed coral, and shells. And it comes straight
from the ocean here in the US. Doesn't really specify where and
therefore I'm being a bit cautious. <<Mmm, might be wise. I believe
there's only a few places where "aragonite" sand is collected...haven't
ever heard any were off our own shores, but I'm not an authority
re. You might want to try/order a small amount and give it the old
"vinegar test" to see how much of/whether it is truly aragonite>>
Thanks for all your help. Jon <<Happy to assist. Regards,
EricR>> DSB..., Denitrator, Substrate Type/Adding Snails -
08/10/06 I have decided to install a DSB in a large bucket after
trying for months to set up an AquaMedic NiTRATE reductor 400, without
success. It would either produce sulphur or nitrate because the turn
flow valve was very difficult to adjust, making it difficult to get the
correct flow rate, the drips were either too fast or too slow, it was a
right pain. <<Indeed...manufactured nitrate reduction equipment
always seems too "fiddly" to me, no matter which design you choose. I
think you will have better luck with the DSB>> During my visits to
various aquatic shops in the area, I am getting many different reasons
for and against the use of DSB's, also the use of various different
types of media. <<Not surprised...some folks love'em, some folks
hate'em...and even among those who employ a DSB opinions will vary on
application. But the basics are the same...a deep enough bed for the
size granulate chosen to permit adequate stratification of the different
bacterial zones>> One that has been proposed is the use of PLAY PIT
SAND; have you any thoughts on this? <<I do...the "play" sand is
quite suitable for nitrification purposes and will perform this function
as well as aragonite sand of the same grain size...but...the play sand
will not provide any buffering capacity and it is decidedly "sharper"
than aragonite which "might" be rough on some of the critters which will
inhabit the sand bed. The play sand will work fine, but my preference
is sugar-fine aragonite sand...or even a "mixture" of the two if
obtaining enough aragonite is an issue>> I was also thinking of
using sand snails to help with the movement of the upper layers of sand
within the DSB. <<You can do this (Nassarius and/or Cerith species),
though it is not necessary. Sand dwelling/stirring critters will find
their way to the DSB in time>> Will they require feeding or will
they manage to survive on their own? <<Possibly...best to let the
DSB mature for several months before adding>> Any feed
back on this would be gratefully appreciated. <<You have mine>>
Phil Bowen England <<Regards, Eric Russell...South Carolina>>
Small Refugium DSB - 07/26/06 I made a 5 gallon refugium that
sits behind my main tank, a ten gallon, with the goals of nutrient
export, pod production, pH stability and increased water volume.
<<Excellent>> I was planning on putting Chaetomorpha, live rock
rubble, and some sand in this refugium and running it on a reverse
photoperiod. <<Okay>> My question is would I see any benefits
from a deep sand bed in this size refugium (the sand area's footprint
would be 5"X15") or would I be better of with a shallow sand bed and
more water volume? <<Everything is relative my friend...considering
the small size of the display, this particular DSB could indeed provide
some benefit>> Thanks a lot for any help you can give me. Eli
<<Is my pleasure to assist. Regards, EricR>> DSB
Canister Filter? - 07/24/06 Hello, <<Howdy>> I just
started the fish keeping hobby and I established a 90 gallon reef tank
in my living room. <<neat!>> While doing research I came across
the process of denitrification. <<Okay>> I came to understand
that Nitrate filters are not reliable. <<Mmm, probably not so much
"not reliable" as "fiddly"...requiring constant attention/adjustment to
optimize their usage>> Instead, I read that a DSB could be very
effective at reducing Nitrates. <<Indeed>> Well the thing is, I
don't want to add a deep layer of sand in my display tank, and since I
can't get a sump (there's no space under the tank) I came up with an
idea that might seem weird: Could I apply a thick layer of sand in an
empty canister filter to act as a DSB filter? <<Mmm, no...aside from
not being a large enough volume to be of benefit, pressurizing/running
the filter will cause the water to be "forced" through the entire volume
of sand. This will defeat the denitrification process as there will be
no "stratification" of the sand bed with the varying levels of oxygen
allowing the different classes of bacteria to form/populate...all of
which are part of/necessary to the process of denitrification>> I
imagine it will fulfill the role of a sump. <<Not in my opinion>>
Please correct me if I'm wrong. <<Since a sump is out of the
question, you might wish to look in to the addition of a "hang-on" style
refugium in which to place the sand bed. Another option would be if you
have room "over" the tank to place a large (salt) bucket half-full of
sand with water pumped up to the bucket and allowed to gravity drain
back to the tank from a bulkhead fitting placed just below the lip of
the bucket>> Also, I live next to the sea, where the sand in the
coastal areas is extra-fine (which I read is preferable for DBS). Could
I use this sand? or is it a bad idea? <<Best not to use it due to
the possibility of introducing pollutants/pests>> One last
question. Concerning macroalgae, how effective are they at
denitrification? <<Not so much "denitrification...is a different
type of host/environment, performs a different function from the deep
sand bed...yet still useful through regular harvesting for removal of
organic compounds (including nitrate) as part of their nutrient uptake>>
Also is there a problem to add those in my display tank (I'm
particularly interested in red macroalgae)? <<Can be done, though
some species can be very invasive (e.g. - Caulerpa sp.) while others
might be quickly consumed (e.g. - Gracilaria) by some fish species (e.g.
- Tangs/Rabbitfish) Sorry for the long read. <<No worries mate>>
Any help will be greatly appreciated. <<I hope I have>> Thank
you. Mohammad <<Regards, EricR>>
Protein Skimming Power/Phosphate/DSB removal 7/15/06
Hello, Thanks for running such a great site. I've learned so much
from reading your Q&A's. < Bob and the others do a wonderful job! >
I have a 55g reef tank with about 50 lbs of live rock and a 4" deep sand
bed. It's about 15 months old and so far everything has been working
very well, except for a recent, steep phosphate spike. Is that typical
for a DSB? < No, that is not typical at all. > (I don't
believe it is from overfeeding.) < Are you feeding frozen foods? If
you are not rinsing the foods well, the phosphate from the juices could
be encouraging the spike. Another thing to consider, if the prepared
foods have fish meal in the first five ingredients, the phosphates could
be coming from that! > Is an extremely high level of phosphate a
possible cause for my losing a number of fish recently, a day or two
after acclimation (which I normally do gradually over about 1-1/2
hours)? (It's not due to a mantis shrimp; there is no clicking, and no
sightings at night.) < I seriously doubt the phosphates would cause
that kind of reaction. I would look more at temperature fluctuations, or
the possibility of airborne pollutants. > After talking to a couple
of LFS, I'm becoming convinced that the DSB will eventually crash, and I
am planning to remove it soon. How gradually do I have to do that?
< A four inch sand bed is not deep enough to really cause a serious
problem, but if you must remove some, only remove an inch or so.
Remember, the sand under the first inch layer is horribly toxic. Don't
stir up too much! > My main question has to do with skimming. I
have an Aqua C Remora (not Pro) with the Maxijet 1200 powerhead and
overflow box (I have no room for a sump). One LFS is saying that that
is not enough skimming capacity for a 55 g tank. Currently I have four
small fish, a cleanup crew of 20 hermit crabs and 15 snails, four small
colonies of mushroom polyps and two small frogspawns, but I hope to add
a few more fish and many more corals. How much skimming power do I
really need with this setup, once the DSB is gone? < That is
directly related to the amount of food you feed, and the frequency of
partial water changes. To place exacting limitations, or requirements on
such is difficult. > < Yet another thing to consider is the
possibility of your source water or supplements containing phosphates.
Be careful when adding anything to buffer the pH, for nearly all related
products use phosphate buffering agents! > Many thanks for all your
help < I hope I was indeed helpful! > Bob < RichardB >
"Sponges grow in the ocean. I wonder how much deeper the ocean would be
if that didn't happen." ~Steven Wright
DSB's...Adding More
Substrate 6/26/06 Hi Crew! <Hello Brett> I've
decided to beef up my substrate by adding another inch or so to my DSB.
Right now it's about 2-3 inches and am planning to add another inch or
so of Arag-Alive Fiji Pink. Will I be safe adding it all at once, or
should I gradually add the sand over a few days?
<Should be no problem adding all at once.> Thanks for any help!
<You're welcome. James (Salty Dog)> Brett
DSB
6/9/06 Hey Crew! Thank you for the great service you
provide, don't know what we would do without you all! I am becoming
more confused by the minute. I spent quite some time researching &
thought I had covered all my bases. I have DSB of 7 inches. I decided
to go w/ depth for a few reasons (filtering, maintenance, & wanting to
keep a jawfish). I read that you were not supposed to disturb a DSB, as
it might "crash" the tank. Now, I am reading that I should "poke" or
"stir" the DSB to prevent a "crash". Can I get your thought on
this? If it does require "poking/stirring", how should this be done and
how often? Again, thank you for the site & any help I can get on
this matter. Take care, Wendy <<Wendy: Intentionally stirring
up the DSB ruins the whole point of the DSB; namely that you need higher
and lower oxygen areas in the DSB to realize the benefits of the
DSB. Best of luck, Roy>> Re: QT screw up, oh
and DSB sand - 05/13/2006 Thanks again for your reply Bob.
The weirdest thing has happened - the ich (or at least what I thought
was ich) disappeared from Regal tang in less than a day. Is that
possible? <Umm, yes... is not really gone... is/has cycled off...
your system is infested... and like that not-so-popular ex-Austrian Gov
of the Sunshine State, it'll be "baaaaack"> - I guess it could have
been micro bubbles but I don't think so since all I have is small hang
on filter and power head as filtration- maybe some sand particles in the
QT ( there is no sand bed in the QT)?. <I suspect you're right here.
This was Crypt> In my other QT, my yellow eye tang has regained its
color and the fish seem happy. I am doing a 10% water change in QT every
2-3 days to help the stress levels. Can a FW dip with methylene blue
remove ich immediately? <Not generally...> That's all I did!!
Any ideas ?- Oh well. On an unrelated matter I have a refugium with
a DSB that I had taken offline for a couple of months. I have decided to
give more space to the Chaeto so I began to remove my 7 inch sugar fine
sand (to use in my new system) when I noticed some black streaks in the
sand and smelled an odor . Can I still reuse the sand and if so do I
need to rinse or recycle it with salt water? <Best to give this a
vigorous rinse at least... the hydrogen sulfide smell should be "all
gone" before re-using... though the black stain may well persist. Bob
Fenner> Many thanks again Deep Sand
Bed - 05/11/06 HI, I was wondering if you could tell me the
proper way to manage a 5-inch deep sand bed? THANKS. <<A rather
nebulous question my friend. Do start reading here (http://www.wetwebmedia.com/deepsandbeds.htm)
being sure to follow/read among the links in blue at the top of the
page...and feel free to come back with more specific questions if need
be. Regards, EricR>> Nano DSB - 04/26/06 I am
a huge fan of the DSB and have had great success with it in my 75 gallon
reef tank at home (thanks to the info on wetwebmedia.com). I have now
started a 24 gallon AquaPod at work so I can enjoy my reef all day.
<Very cool! I want one at work too! But just remember – you’re working
with a whole different animal here now that you limited your water
volume to such a small amount.> I employed a 4 1/4" oolitic sandbed
with 25-30 lbs of LR. <Sounds nice – however severely limits your
volume once again, you will have to be much more careful here, won’t be
as forgiving as your 75g> I also threw in a couple scoops of sand
from my DSB at home to seed it with some pods and worms. The tank is
stocked with 2 small Chromis, a very small ocellaris and the usual
assortment of janitors. <Just fine amount of bioload here.>
Corals include a pom pom xenia, star polyps, Fungia sp, assorted zoo's,
2 Ricordea yuma, and other various mushrooms. The Nitrate has steadily
risen in the AquaPod (unlike my tank at home that has had undetectable
levels for almost 2 years) it's currently around 50ppm after 2 months.
<Ouch, much too high here – especially stressful for your inverts. You
have much too much in this tank given its only 2 months old.> Is the
DSB just not deep enough for a volume this small, maybe it needs more
time? <I wouldn’t add anymore sand here, you already have little
water.> I don't think the bioload is anywhere near "too much" fish
wise and I feed very sparingly. <Bioload is fine.> I run a
micron filter pad, changed daily and use RO for top off. I'm planning on
buying a little skimmer for it, but don't have great confidence in the
cheap ones that can fit in an aquarium like this (current's fission
skimmer). <Absolutely must have a skimmer here. Personally I’ve
found that the fission doesn’t do much. Adding a sump/refugium with a
better skimmer like the Remora, would be the best option.> Would it
be worth slowly adding another inch or so of sand? <I wouldn’t, no.>
Any ideas are appreciated. For now I'm just going to go back to weekly
water changes until I get things figured out. <Keep up your water
changes, it is possible that you haven’t quite cycled completely
though. You’re really high and you have enough in there to add to it
daily. Next time, with a volume so small, I would wait a little longer
than you did before adding inverts precisely for this reason. Good
luck, Jen S.> Thanks so much, Jeremy Re: nano DSB For Jen S.
4/27/06 Thanks for your reply Jen. <No problem Jeremy!>
Your right, that is a lot of coral for a 2 month old tank. They have all
been frags from my big tank so pretty much free (it's hard to resist
bringing them with me to work!). <I get you here!> Anyways,
I just wanted to let you know that if you really do want a nano for
work, fostersmith is selling these 24 aquapods on special for only
$169(shipping was $13 so its like 25% cheaper than I've seen anywhere)
for the next week or 2. <Thanks for the info – I ALWAYS order from
them, but I don’t believe I’ll ever go nano reef tank again (I have a
12gal up and running among others.) There are just too many mod.s to
make to these already built systems.> They do run a bit hot and we
had to mod them with some additional fans in the light cavity and some
breathing ports on the outer shell to evaporate the condensation.
<Great mod.s, you should have seen me adding proper lighting to an
eclipse hood!> All and all I am pretty happy with them so far. I'm
going to try and shave 1/4 off of a Berlin airlift 60 skimmer nice and
quite plus no extra wattage in the tank) crossing my fingers....it
should fit in the back chamber. <Great luck! I just added a
sump/refugium to add the skimmer into, among the many other
benefits. Thanks again for the info! Jen S.> Thanks again!
Jeremy
DSB and Confusion(s) - 04/19/06 Hello to
the WWM person of the day! <Guess that is me, Adam J with you
today…..’err tonight.> I have a 100gl tank which I purchased
recently and when it was moved I saved half the water, as well as most
of the sand. <Okay.> I set it up as a reef, with 4" DSB, but
kept having algae blooms because one powerhead blasted a corner and
stirred up the sand too much. <Common problem with DSB’s.> At
this point I decided to remove a pesky tang and Anthias, which came with
the purchase, so having to basically break down the tank to catch them,
I moved all the LR to my 40gl tank with no sand bed. <Okay.> OK,
here's where things get fuzzy...I decided I would like to keep the
smaller tank as the reef tank instead. <All right.> It has
plenty of pods and critters and I want to set it up as a Seahorse
exhibit. <Be sure to research the needs of these creatures, not an
endeavour I recommend to just casual aquarists.> Now for the
100gl...It has been sitting for 3 months with old water, no light, no
heat, etc. <What about flow, was it stagnant.> I drained nearly
all the water, and to my surprise, a few snails (who got left behind),
were still moving along in there. With the tank sitting so long with out
any attention, is the sand still viable? <Sure.> I am planning a
FOWLR, so I need to decide what to do with this sand. <Keep if you
want, but once the tank is in “working” order again I would allow a
minimum of 30 days to let it stabilize.> Do I clean the sand
entirely with saltwater, remove it completely or just the top layer?
<I would vacuumed any detritus out of it, stirring if necessary since
there is no livestock in the tank.> Would it be usable for the 40gl
tank? <You could, but moving it will disturb the anaerobic pockets,
it will cause the “levels” in the 40 gallon to go array…this is fine if
their isn’t any livestock in there yet.> If I want to add sand to
make it deeper, would I want to add sand a little at a time or could I
put in another inch all across and stir it up a bit? I assume curing any
new LR might be done simultaneously. <That’s what I would do.>
This would all take place before any inhabitants move in, <Great,
that’s what I was concerned about.> of course. Trying to juggle
setting up two DSB's at once is giving me a real headache. Please help
me stop the "spinning room" syndrome! Thanks! <Adam J.> Re:
reusing an old sand bed 4/25/06 Thanks for
clearing the confusion Adam. <He seems to have skipped town...>
No, there is no water flow in the big tank. I'll do as you recommended
and simply siphon off the sediment along with stirring up the top layer
of sand. As for the 40gl, it does have a couple of fish (a fire fish,
plus a small clown who will be returned to the 100gl ), also Xenia,
hammer, GS polyps, a feather duster, along with a couple of turbo and
Ceriths, hermits and a Choc. chip star (which will go back in the 100gl
when its livable). I do have some experience, along with all the
research I'm doing, to feel confident making the reef ready for horses.
Here's my next question... should I retrofit a DSB with new sand into
the 40gl? <Could... as you'll see/find, I am a big/ger fan of
remoting such in separate tied-in sumps/refugiums... much easier to
maintain, manipulate> As mentioned earlier, all the rock and
inhabitants were originally placed in there as a holding tank with out
any sand bed. I do have plenty of pods and such living in a few clumps
of Chaetomorpha (Brillo pad) algae and I've see nano tanks kept without
one, but I wouldn't be able to put a fuge on the back. On a scale of
1-10, which would you opt for? Also, I plan on returning the bio-balls
to the big tank's sump, in addition to keeping the DSB. Any concerns?
Thanks again <Sorry, don't understand your stated options
clearly... I would choose the largest/r 'fuge... place the DSB there.
Please read here:
http://wetwebmedia.com/marsetupindex2.htm see the area about
four "paragraphs" down on Refugiums? Bob Fenner> DSB
For A Large Tank - 04/09/06 Dear Bob, <<EricR here this
morning...I think Bob is still asleep/recovering from his Lavaman ordeal
<grin>.>> I currently have an 8ft tank and would like to add a deep
sand bed to assist in denitrification and to provide more comfort for my
stingray. <<A very good idea in my opinion. I too have a 8ft tank,
with a 6" DSB...but no stingray (is a reef display).>> I have read
the article on the website, and am aware that 3" depth is a minimum.
<<Mmm...can depend on 'grain-size' of the substrate, with larger
grain-sizes meaning deeper beds. But even when using sugar-fine sand my
preference is for a 4-inch minimum.>> There is 40kg of fine coral
sand, 12 kg of fine grade aragonite currently in the tank which makes up
an average depth of between 1-2 inches. I will create the DSB by adding
sugar fine sand, although I would like your opinion as to how deep I
should go? <<Were it me, with this mix of sand, I would shoot for an
absolute minimum depth of 4 inches...even 5 or 6 inches if your not
opposed to the look/loss of depth to the open water column. I know
that bigger tanks require deeper sand beds. <<Not sure I agree with
this. All things equal, the sand bed will be proportionately larger in
the larger tank. As far as I'm concerned, 'minimum' bed depths would
apply equally to all tank sizes.>> Current inhabitants included a
small masked-stingray, 3 snowflakes. <<Sounds like a very nice
display. This ray (Dasyatis kuhlii) seems to be one of the better
choices for aquariums (not to be confused with Taeniura
lymna...another/different 'blue-spotted' ray with a very poor survival
record) and will definitely appreciate a 'fine' sand bed.>> Also, I
have attached a spare 10g tank as a refugium (which I know is small, but
at least it puts the tank to good use) and would also like to know if
creating a deep sand bed in there, without having a DSB in the main
display, would have any sort of effect on denitrification?
<<Probably not a noticeable effect...considering the size/stock list of
the display. I think putting the DSB in the display is your best
option.>> I'm just trying to get my head around the proportionate
area of DSB and its correlation to the degree of denitrification.
<<Please have a look here: http://www.wetwebmedia.com/deepsandbeds.htm
>> Thanks in advance, Joe <<Quite welcome. Regards, EricR>>
New CaribSea Aragonite Substrate 4/6/06 Good
afternoon gang! <Jeff> I just purchased a bag of the CaribSea
Aragonite to add to my growing 55g FOWLR tank. Once home I found a hole
in the bag. Should I set up a QT for this sand, or would it be safe to
add to the tank as is? <Very likely fine as is... just rinse (for
dust mainly) and pour in> Also, I am increasing my DSB to
somewhere between 3 and 5" based on what I have been reading on the WWM
site. I currently have between 2 and 3" of sugar sand with a mixture of
crushed shells. I have approximately 50#'s of crushed coral that I took
out of the tank when I added the sand. Can I mix some of that crushed
coral with the aragonite to get my DSB where I want it?
<Yes> The reason for the DSB was to get away from vacuuming the CC
every two weeks. I don't want to add the CC if I will have to go
back to that biweekly cleaning regimen. <Still will need to be
stirred a bit... See WWM re DSBs> I am also getting ready to add
48#'s of live rock, already have about 12lbs in tank, once it get
through the curing cycle. With the addition of the LR and the
increased DSB, I am wanting to remove the bioballs I have in my wet/dry
filter. <Should be fine to do> This tank has been established
for about 2 years. Nitrates have always stayed around 10 to 20
PPM. With all I am doing/want to do, with regular water changes, am I
headed in the right direction to get nitrates down to zero?
<Yes... perhaps a later addition of a refugium...> Thanks in advance
for your help! Jeff <Welcome. Bob Fenner>
Re: New CaribSea Aragonite Substrate 4/6/06 Thanks for the
reply Bob!! <Welcome> You mentioned that the sand/CC mixture
would have to be stirred around a bit....I have about 75 Ilyanassa
snails currently in the tank to keep the sand stirred up. Will that
work? <Should... perhaps but a bit of "grunge" that you might want
to stir at the edge where the viewing panels might show it> These
snails are about the size of a dime and seem to be doing quite well.
...or do I still need to stir it up about every two weeks or so?
Thanks again!! Jeff <Likely no need here. Bob Fenner>
DSB and Live Rock Quandary 4/1/06 What is right?
Good evening from NC! <Good evening to you too!> I have a 55 FOWLR
tank that has been up and running for about 2 years. I currently have
about 12 lbs of rock, some coral skeletons, barnacles, shells, and a 3"
sand bed. Water conditions are acceptable: ammonia - 0, nitrites - 0,
nitrates - 15 to 20ppm, PH - 8.0 to 8.2, SG - 1.023-1.026....the latter
three vary a little with water changes. The rock I currently have in
the tank is partially in the sand, with one piece on top. I have
recently purchased 48 lbs of Fiji Premium rock and have it curing
now. It is currently in a 35 gal covered trash can with a heater, air
stone, and a power head...I do not have an extra skimmer...so I hope
what I have will work. I am closely monitoring the ammonia and changing
water as needed per what I have read. <Sounds good.> My question
is....after curing, should I move the sand and set the rock on the
bottom of the tank, then push the sand around each "base"? Or set it on
top and try to "wiggle" it into the sand? I only have three fish at
this point....2 damsels and 1 blue tang...along with 1 blue leg hermit
and several small snails. I would like to add an anemone and a pair of
clowns once I get everything in place and all the water conditions
stable. After reading WWM for hours it seems, I know that the rock will
need to stay clear of the back and sides for cleaning purposes. I am
just not certain about the sand placement. <This is really your
preference. Either way you have to make is stable. Setting it up with
no substrate is one way to do it. However you can also use a cement
designed for SW tanks to stabilize it also. It's really what is easier
for you. Good luck! > Thanks in advance for your input. Trust
me....it is very much appreciated!! <No problem, Jen S.> Jeff
Regarding the use of Macroalgae and DSB in a unorthodox remote manner
2/26/06 Crew, Hope you are all well. <Doing well thank you!
Tim answering your questions today.> I have been unable to find any
reference to this idea and would like a singular or collective opinion
if you have interest. For those of us who have smaller reef systems
with no room for refuge, sump, etc. (at least no room we are allowed in
the living room or I would have 10 interconnected tanks); <My situation
also at present... though stay tuned as I am intending on soon posting a
useful article regarding this issue!> Here are my assumptions -
Since macroalgae does a wondrous job ( specifically Chaeto and Caulerpa,
Chaeto being my preference ) <Mine too - Caulerpa has a host of problems
of its own!> in the removal of dissolved organics/excess nutrients -
and a DSB if maintained properly can be wondrous as well - and a DSB
can be remote Could it be possible to have a non-connected system
(i.e. LARGE Rubbermaid container) with the proper heat, moderate
circulation and enough lighting to effect macroalgae growth, to
basically use as a tank water purifier. I can envision swapping 10
gallons of change water out of the tank with 10 gallons out of the
remote system and letting the DSB and macro 'process' it for later use.
<I would not recommend this, although I appreciate your thinking. The
reason is that doing water changes do not simply reduce the level of
DOCs in the water, keeping nitrates and phosphates under control, but
also i) removes a variety of other chemicals that may be in the water
that may not be filtered out by algae or a DSB, for example the toxins
released by some corals and other animals ii) water changes actually are
important for adding chemicals to the water, in particular trace
elements that may become depleted otherwise. Of course with regard to
the latter, you could supplement these manually with additives, but I
would still be concerned about a potential build-up of toxins in the
water.> I could set this up in the garage even in colder months with
the proper insulation and heating and have an available supply ready to
use as change water. Would also ensure that when/if the DSB got icky or
Caulerpa went crashed, there would be no main tank crash. Just a
wild thought and thanks for any input, if you feel its warranted. <I
would recommend avoiding this option> My only other options is to
hypnotize spouse to put a 120g in the formal living room that can have a
refugium...<If you manage this, please do tell me your technique as I
have been trying the same for some time now, but so far my spiral
print-outs have been unsuccessful!>.but she might see that coming..
Take care, Bill Re: Regarding the use of Macroalgae and DSB in
a unorthodox remote manner - 2/28/2006 <Hello - Tim
responding again. I hope that you are well!> Yet another reason that
WWW is one of the best sounding boards <Thank you very much - we do
try!> - that is an EXCELLENT point - I thought that I had thought
all the options through and the non-exported 'stuff' simply did not
enter my brain. <Thank goodness - most of it is the kind of 'stuff' that
you do not particularly want entering your brain either! :o) >
Especially considering the new dragonette that I just got acclimated and
has been spewing a little mucus during acclimation :) <Do ensure that
your tank is adequate to support this lovely little fish - or that you
have a replenishable source of copepods!> Interesting how diatoms seem
to be attracted to any amount of mucus from every nook of the tank.....
ewww.. Oh well, water changes it is :). I also noticed that one of
my Strombus snails appeared to be expelling multiple cloud bursts of
gametes - I thought most all snails copulated in some way and then
laid egg strands - is this something you have ever seen? <No I am afraid
that is not something that I have experience with - perhaps other
members of the crew will be able to comment on this. In any case, do
check the WWM site for more information.> I can't imagine it is an
efficient way of reproduction with the speed at which they move :)
<Interesting point!> I could not get a pic fast enough, then it went on
its merry way cleaning the rock.... Take care DSB maintenance
2/24/06 <Hi Steven - Tim answering your question today!> I
have a question regarding the maintenance of my DSB. First I should
describe my system. The tank in question is a 55g FOWLR containing a 5"
bed of fine aragonite with about 80lbs of rock. Its inhabitants are a
pair of Clarkiis and a cleanup crew consisting of a few large Turbos,
some Nassarius snails, blue-legged hermits, and a diadema urchin. This
tank flows down to a 10g dark refugium (used for plankton generation)
and then into a 29g illuminated sump housing various soft
corals. Filtration is largely natural with the except of small amounts
of carbon (changed weekly) and a Seaclone 150 skimmer. <Is the skimmer
working for you? I have read mixed reviews.> Now
for the DSB question. My concern is that I have not been properly
maintaining the sand bed. I have heard a lot of mixed opinions
regarding the cleaning of DSBs. Some say to occasionally stir the top
inch, others say to stir the whole sand bed, and some say to vacuum the
sand. I have been doing none of these. Instead I was assuming that the
Nassarius snails would adequately stir the top inch as well as remove
detritus. Do you think that this is sufficient? <Review the information
at
http://www.wetwebmedia.com/deepsandbeds.htm and the related links
with regard to proper maintenance of a DSB. In terms of the Nassarius,
their adequacy will depend on the number in your tank; the blue hermits
will also help.> Or should I begin a cleaning regimen? <Always a good
idea - especially in terms of vacuuming the surface of the substrate.>
If I do start cleaning the sand now am I putting the system in danger by
releasing excess nutrients and/or hydrogen sulfide? <This should not be
a problem, though will depend on the age of the sand bed and the extent
to which your cleaning crew have been keeping things tidy.> I guess I
was thinking about starting to vacuum the sand and starting by doing
only a small fraction every few days so that if there is hydrogen
sulfide release it will be on a smaller scale. <Always better to be
safe, I agree.> And one more question regarding
the tank's set-up. When I set up this tank I first laid down the sand
bed, and then placed the rock on top. The rock covers approximately
half of the DSB surface area. Was this a mistake? Recent reading
suggested to me that it is a mistake because the area underneath the
rocks will not be reached well enough by the detritivores and can't be
stirred by myself without removing the rock, so it will end up being a
large nutrient sink. I guess my thoughts during the set-up were that
rock on top of the sand would be fine because uneaten food/waste would
not settle under the rocks and so this area would relatively
nutrient-free with the except of small amounts of organics seeping in
from neighboring uncovered portions of the bed. Furthermore, the rock
placed atop the DSB should aid in creating the hypoxic conditions
necessary for natural denitrification, correct? Your opinions are much
appreciated! And huge thanks to the entire WWM crew for taking the
time to make us all better aquarists! DSB layered sizes -
2/21/2006 Hey guys, First I want to thank you all for the
great information on the site. It is truly invaluable. I have a question
regarding a DSB in a 24 gallon nano tank. I have used a 4-8" DSB in my
75 gallon reef tank for over a year (I know that's a big difference, the
current has done lots of shaping). I used Aragamax "Select Grade", and
the nitrates are undetectable. Needless to say I am very happy with it.
So this is my question, I am starting up a 24 gallon AquaPod (I hope
these ones don't crack!) at work to keep part of my reef with me all
day. My LFS does not carry the Aragamax "Select Grade" that I used for
my first DSB. They do have the "Special Grade" which is still pretty
fine, but not sugar fine. They advertise the Special Grade as 1-1.7mm.
Is this Ok to use, or should I wait until I can get the true "oolitic"
size? <I would use either... the one on hand is fine> I was
thinking that I could put down 3" of the "Special", and then maybe 1" on
top of that using the "Select" I have some select left over). I can also
get a "super fine" 0.2 to 1.22 mm, I was worried that may be too small.
What do you think? Thanks, Jeremy <If mixed, will mix... Bob
Fenner> Refugium Methodology...Reverse Flow DSB? - 02/11/06
Hi, <<Hello>> I have a 210g reef tank (200lbs. LR and a large
number of corals) with a 40g sump and a 40g refugium. <<cool>>
Lighting is an Aquamedic space light with 3-250W 20K HQI. My skimmer is
an Aquamedic model, not sure of the model number but I have found it
to be excellent. <<ok>> The pump for the return is a Dolphin
3000gph. I have been toying around with various ideas to try to improve
on the refugium because it's not doing what it is supposed to do which
is act primarily as a nitrate reducer. <<I see...>> In talking
to various people, I came across an idea that intrigued me but have not
been able to verify it. In a nutshell, it uses a plenum (~2"tall) and
has approximately 5-6" of sand on top. <<You don't need the
plenum...>> The interesting part is that a pipe is run under the
plenum and water is slowly pushed thru the sand and then returns to the
main tank. <<Hmm...ok>> I have not been able to verify the
effectiveness of this, and while I don't mind experimenting, I would
prefer not to do anything that would have a truly detrimental
affect. Any ideas would be great. <<I'm not familiar with this
methodology...for my two cents, I would employ a simple lighted
vegetable refugium with a 6" sugar-fine DSB and Chaetomorpha algae. But
if you're interested, do set up a test system as described, and let us
know your findings.>> L <<Regards, E >>
DSB and
ammonia production 2/7/06 Robert or WWM person.
<Okay> I understand that under some conditions a DSB or other
anaerobic nitrate reduction can return ammonia instead of nitrogen
gas. This has resulted in a civil discussion between me and some
others. 1) Is my point correct and there is some way however remote
a DSB can return ammonia instead of nitrogen gas. <Yes> 2) is
the poster correct in his assessment that the page on WWM is incorrect?:
from: http://www.wetwebmedia.com/FWSubWebIndex/fwnitrates.htm
quote: This occurs in two half-reactions Nitrate to Nitrite to
Nitrogen NO3 + 2 electrons + H+ <=> NO2 + H2O NO2 + 3 electrons
+ 4 H+ 1/2 N2 (nitrogen gas) + 2 H2O or, taken together: NO3 + 5
electrons + 6 H+ <=> 1/2 N2 + 3 H2O Where some anaerobic microbes
(lack of oxygen) convert nitrates into transitory nitrite and ultimately
ammonia molecules. Note, with the use/incorporation of H+/protons pH is
elevated. Note further that this is where the reduction of carbon-based
materials comes into play in "feeding" purposeful denitrators, providing
the electrons and hydrogen ions, balancing these Redox equations.
<This/these are valid statements... though not (necessarily, very)
complete> unquote poster: quote: That is his entire
discussion of the chemistry of denitrification. Note that he heads his
listing of the equations "Nitrate to Nitrite to Nitrogen," that none of
the equations contain ammonia, and that the only reference to ammonia is
in that singular sentence. Note also that aqueous ammonia in your tanks
exists as ions, not molecules. <Mmm, the "chargedness" of chemical
species has nothing to do with whether they are molecular or no> So
the sentence as it stands, taken in context, seems incongruous. A
reasonable conclusion is that his mention of ammonia in that sentence
was in error; <Mmm, just an omission> that he likely meant to
say "some anaerobic microbes (lack of oxygen) convert nitrates into
transitory nitrite and ultimately nitrogen molecules." <Okay>
unquote and emphasis added. To me your site said exactly what it
meant to say. That under some conditions it is possible to generate
ammonia not nitrogen gas. But under normal (say low ph values) you get
nitrogen gas. <One common set of conditions, yes> thanks in
advance. Bob <... I would like to make complete declarative
statements re this (and other important aquaristic) topics... Am
wondering though, how much utility/popularity these would enjoy. Cheers,
Bob Fenner>
DSB invention 02-05-06 Maybe a new
invention Hi all. I’m a saltwater fish enthusiast. And I had an
idea that may work to reduce nitrates. If one built a chamber with a
four foot long piece of 3" pvc and had a 3" to 1 1/2" adapter on
each end. And filled the chamber with 2-4mm aragonite substrate. Then
pump water through it. Could there be the Anaerobic bacteria in there
that would reduce the nitrates? Maybe this is something that people are
already doing. Or maybe it wouldn’t work, but it sounds good in
theory. What do you think? <First off, you would need a pretty powerful
pump to push water through 4' x 3" of aragonite. You would in essence
be pushing aerated water through it so that would eliminate the
anaerobic function. Much less fooling around if you just went with a
DSB. James (Salty Dog)> Nick Myrtle Beach
Question
on DSBs 1/27/06 Hello Crew, <Jennica> I've
read your Reef Invertebrates book. The book and your website appears to
-very- strongly recommend using sugar-fine sand (e.g., like CaribSea
Aragamax sugar sand), but the reference chart at CaribSea (http://www.carib-sea.com/media/aquatic/reference.jpg)
gives these sizes only a "G" rating at best for use in deep sand
beds. Only the grains the next size step up earn the "E" rating. Do
you know why that is? <Mmm, nope> I'd really love to
pursue a DSB not just for the denitrification, but also for the
opportunity to watch interesting creepy crawly critters in action.
Regards, JJ <Do contact CaribSea here... and make known what
they say. Thanks. Bob Fenner> Re: Question on DSBs
1/31/06 Hello Crew, <Jennica> Per correspondence below, I
emailed CaribSea regarding their "Good" grading for the sugar-sized
Aragamax sand as opposed to "Excellent". This is their response:
"It was simply an oversight while creating the new catalog, and website.
It will be changed to excellent in the updated versions." Thought
you'd might like to know. Regards, Jennica <Ahh! Thank you
very much for this follow-up... Seems the folks putting the catalog
together made up a classification scheme but forgot to revisit and put
"real" (relatable prompts) in its place before sending to the printer.
Bob Fenner>
Replacing Sand, Building Depth Back Up -
01/05/2006 Hello, <Hi there Anne.> I've looked through
the questions but haven't come across one that answers mine........
<Ok.> I have been taking out small amounts of sand during my weekly
water changes (the last three times) that seem to have Cyanobacteria
growing on it. <Hate it when that happens. You can try a smaller
diameter tube, should help.> I'm starting to notice my DSB isn't so
deep anymore. Is it ok to add sand back into the tank a little at a time
to build this back up? <Yes, and you're right, a little at a time.
When adding try moving small portions, add the new, smooth the old back
over. Don't bury the existing bed.> Thank you <Gladly. - Josh>
Anne Canfield Staff Research Associate II California National
Primate Research Center <Awesome. I love 'em!:)> Deep sand bed
I can't seem to get my nitrates under 20ppm even with weekly 10%
changes. <As you (will) know, there are a few key inputs/outputs
here...> I was/am thinking of converting to a DSB. Right now I have
25 lbs of crushed coral in the tank(50g) as a substrate. Would I
benefit from replacing the crushed coral with sand? <Perhaps> If
I add sand, should I leave the crushed coral or remove it? <If there
is room, I would leave it, have both> One local "expert" just told
me that sand will eventually kill a tank as it traps all of the nitrates
and phosphates until one day it all gets released into the tank.
<Mmm, well... there is some factuality to the statement...> I'm
thinking that if a maintenance crew of crabs, snails, sand sifters, etc
are in place that should take care of that concern no? <This and
periodic replacement, addition of material, yes> Now, I do have a
fuzzy lion and I'm fearful that any shrimp I add he will just eat, so
there goes part of the cleaning crew. Thanks David <Please
take the time to peruse the articles and FAQs files archived on WWM re
DSB's, Nitrates... marine substrates period. Bob Fenner> Re:
replaced deep sand bed 1/10/06 Hi all, I am sure
I should of given you more information. This is a 55 gallon tank with 1
year old 60 lbs of live rock. There is an internal refugium with sand
and rock and macro algae. I hope this is enough information. I really
appreciate your support. Thanks Ernie <... sounds good. Bob
Fenner>
Moving A DSB...No Party - 12/06/05 WWM DSB
Guru: Hello, <<Howdy>> I'd like any advice you have on moving a
DSB. <<Generally not worth the bother/mess to try to move the entire
bed...is up to you...but I would place new sand in the new tank and just
seed it generously with sand from the old tank.>> Currently, I have
about a 3-4" sugar-fine Oolitic DSB in a 100 gal. reef that's been
happily gobbling nitrates for 2.5 years. <<Very good!>> I'm moving
all of the livestock to a larger tank. I plan to move the LR and the
fish first, then slowly scoop out sections of the DSB, rinse it
gently in remaining tank water, and replant it in the new tank at about
10 lbs per day (I think I have about 150 lbs total to move.).
<<Mmm...see my previous comment. Do be aware that relocating the old
sand bed will cause a die-off of micro-/macro-life within the bed as the
different levels/layers become mixed together.>> DSB critters like my
sand sifting starfish will move after the bulk of the sand gets moved
into the new tank. I'm planning on avoiding moving the whole thing at
once to avoid any noxious sulfur based gases getting dumped into the new
tank, or any other nasties that might be released upon disturbing the
bed. <<Of little concern.>> I'll disturb quite a bit of the
anaerobic bacteria, <<Among other things...>> obviously, and might
require months of maturation before the newly transplanted DSB is
working at full throttle again, I assume. <<Not much difference here
between this or heavily seeding a new bed eh?>> Is this the correct
approach, or do I need not worry and can move all at once? <<I don't
recommend moving the entire bed unless the tank will sit fallow until it
cycles. Whichever method you choose, consider placing the fish/livestock
elsewhere until you can test/confirm the safety/stability of the new
setup. EricR>> Cheers, SLC Water flow and the Deep
Sand Bed 11/30/2005 Hello Crew <Hi.> I have a small matter,
I was hoping you could guide me to put an end to my tank being cloudy
from my circulation pump stirring the sand bed. <Okay.> - 120 gal
all-glass - 4 in DSB - return manifold schematic used from your
WWW forum
http://www.wetwebmedia.com/pbh2oret.htm, thanks a million for this
thread. - return pump; external HD Blueline A.K.A. pan world magnetic
pump model 200PS <Sounds good.> The pump is rated @ 1750PH @ 0 ft
head - max ft head pressure 39 ft. I have calculated my plumbing system
including the manifold to approx 10 ft head giving me 25 gpm or 1500 gph
per the flow chart schematic. I had the system running approx 4 weeks
prior to putting any lights to the tank. Now that the lights are up, I
have noticed a large amount of sand mixing in the main tank and the
water movement is pushing the sand bed out of conformity on the sides of
the tank; actually displacing the sand completely as the glass is
visible on both bottom sides of the glass tank. Not to mention the tons
of microbubbles developing from the water rushing through the refugium /
sump to the return pump to the tank. <Seems like the micro-bubble
problem could se solved with a few strategically placed baffles.> I
know I know, too much water movement. :((, I read many articles
including your books and many other readings pushing for min 10 x the
main tank volume min. I know that having 100/lbs LR, approx 120/lbs Arag
DSB displaces the water volume for sure maybe 90 - 95 gal( I am not an
engineer I only have resource material for reference). I have cut down
the return pump ball valve almost 2/3. I have 1 - 3/4" loc line flat
nozzle agitating the surface water wonderfully and, the other 3/4" round
nozzle placed 1" below water level positioned for deeper water
circulation around the rocks and tank. No matter what I do the only way
to reduce the sand mixing is too almost shut the valve close to almost
1/4 open. This reduces the stirring of the sand completely but, my fear
is now I am almost certain I am not even obtaining 3 x water volume
circulation. I have invested in the
http://secure.microbyte.net/virtual/webaquatics/onlinestore/detail.cfm?ID=OS1142&storeid=1
water flow gauge but it is ordered and I have to wait until I get it to
know what my water movement could really be. I was curious, is there any
other way to get the tank's sand to a more stable situation with my
current water pump configuration? <Well this is one of the downfalls
about keeping a DSB in a high flow reef tank. Your exact problem is why
many hobbyist prefer to keep the DSB in the sump/refugium area rather
than the display. I would rather you not sacrifice the flow rates by
closing the valve, I’m a huge proponent of LOTS of water flow. I have
had this problem before and it came down to the way my return nozzle was
aligned. IT was aligned much to liner and the flow was going directly
into the sand bed. I remedied this by creating a much more turbulent
flow environment by positioning the returns aimed directly at each other
or other obstacles such as rock and glass and other power heads.>
Thanks in advance and thanks a million. <I hope this has helped.>
Sincerely Maurice Rousseau Jr. <Adam J.>
DSB in 20L? 11/29/05 Hello crew! <<Howdy>> This is a
great site, and your archives have answered many of my questions.
<<Excellent to hear.>> In searching I found several people using
20L's for sumps, but no discussion about 20Ls and DSBs. <<Ok>>
I am opting to go with a 20L (36x12x12) for a sump on my 90g AGA
MegaFlow tank (600 gph overflow, 48x18x24). The sump will contain a
Euro Reef CS6-1, 2x200w heaters (should be able to fit them across
with width), and a MagDrive 9.5 return pump. <<Sounds good...I
personally love the ER skimmers.>> I like the idea of a remote
DSB. <<Many do>> The layout will be similar to the plumbing
diagram you show at the bottom of this page (but with one overflow):
http://www.wetwebmedia.com/plumbingmarart.htm. <<A popular
design.>> I have a not-to-scale sketch that I made at
http://filebox.vt.edu/users/stwalker/ReefPics/Sump.JPG.
<<The page would not display.>> <<URL showed one too many
slashes, works fine now, but posting here for your viewing
pleasure. Marina>> |
Click the link above to find full-size diagram on querier's
site.
| The lower height
of the 20L (12") makes for easier access since I only have 23
in. available from the bottom to the top of the stand. However,
I'm concerned that 12 in. will not be enough height to leave
space for power outages, and still be able to run a DSB w/ macro
algae. <<Will limit volume, yes...have you considered/done a
test fit with a 29 gallon tank?>> ReefCentral's sump volume
calculator states I'll need 7.5g to handle the tank overflow
which equals about 4 inches of height in the 20L leaving 8
inches for use. <<I recommend you use the calculator as a
rough "guide"...perform your own volume check once all is
installed.>> Considering the size of the skimmer and return
area leaves ~1/3 of the tank for the refugium area. <<Which
is why I prefer separate sump/refugium when possible.>> Here
are my questions: 1) Will a 4" DSB and 4" area for macro
algae work and provide some benefit? <<Certainly...though in
this instance bigger is definitely better...>> 2) Is there
something you would change about my plumbing diagram?
<<Maybe...if I could see it.>> 3) Would I be better served by
using a mud substrate and more area for macro algae, or should I
look into a larger sump to be able to run a DSB? <<My
preference/experience is with a DSB...I would opt for the larger
sump if possible.>> I'm still in the process of setting up,
and haven't purchased a QT tank yet, so I could use the 20L for
that if a larger tank is a better option. <<Ok>> Since I
can't fit the 20L through the stand doors anyway the only
affect of a taller tank will be that removing the skimmer would
be more difficult if I ever needed to do so. <<And you
will...for periodic maintenance/cleaning...all must be
considered.>> Would modifying the stand to have a side access
door be a good idea? <<Mmm...if "modifying is an option, why
not customize/build to accommodate a larger sump (and maybe a
separate 'fuge too?).>> Thank you for your time. -Steve
<<Regards, EricR>> |
Juwel Filter
Conversion - 11/25/05 Quick question, would it be possible to
place a deep sandbed in the internal filter of my Juwel reef tank?
<<A DSB can be placed most anywhere...many aquarists prefer placing them
in sumps, refugiums, old salt buckets, etc., rather than in the main
display.>> Currently it only house the pump heater and a bag of
Rowaphos, I should like it be put to good use. <<Add some
Chaetomorpha atop the sand bed and some light (RDP), and you'll have a
nifty little vegetable refugium.>> Thanks in advance, Will
<<Welcome, EricR>> Deep Sand Bed Maintenance - 11/15/2005
If I go with deep sand beds instead of crushed coral how do I clean the
sand since you can't gravel vacuum? <Various sand sifters are
available. Most important however is strong water flow, regular water
changes, not over feeding and effective skimming. Read this link, and
follow the links above,
http://www.wetwebmedia.com/deepsandbeds.htm . Oh yes, and I forgot
to mention earlier that your Tuskfish does need live rock, or at least
some suitable hiding spaces. - Josh> Thanks Tony
Miracle Mud & DSB...Can I Use Both? - 11/10/05 Hello There
<<Hello>> I love your forum, your assistance and guidance is an
absolute wonder for the Aqua-ciety. <<We're pleased you find it
useful.> I have a quick question, I did read your FAQ's and I did not
come across any discussion or topic specifically about using a DSB and
Eco-System filtration combined. <<ok>> My setup - 120 gal, 6"
aragonite DSB, 100/lbs live rock. I am wondering 1 thing. According to
the Eco-System website installation procedures, they specifically
instruct the public NOT to use more than 1" sand bed in the main tank
along with their filtering system. I have read your pages on DSB's and
I agree for a DSB for main tank filtration but I wanted to add the
Eco-System refugium below the tank for extra filtration. Do you
recommend using a DSB 6" inline with the Eco-System/refugium with their
product MM (Miracle Mud)? <<No reason you can't do this. The choice
is yours to either follow the Eco-System procedures exactly, or in your
case since you already have the DSB in the tank, to use a "modified"
version. I don't think employing both methods together is going to
"hurt" anything.>> Any insight would greatly be appreciated. Also, I
was curious to know if I had to read your comments on the web or would
you be so kind to email me directly? <<We do both...we post and
reply.>> Thanks in advance and thank you for you wonderful efforts in
this hobby. Sincerely, Maurice Rousseau Jr. Adding sand
where once there was none - 10/20/2005 Hi! <Hello> Great
site! Can I add a DSB to my 40g tank that currently has no substrate at
all?<Absolutely!> And is it as simple as pouring it in?<Essentially
yes.> My tank is occupied by 3 fish, 2 maroon clowns and a yellow
Tang<We all make mistakes> (who will be going to a bigger home soon, I
promise).<Yay!> <Sounds like a plan. http://www.wetwebmedia.com/refugdsbfaqs.htm
This link will help you out. - Josh> Dan
DSB's, depth,
gasses 10/20/05 Crew- <Craig> I was doing some
follow up on your FAQ's about substrates and DSB's and I noticed that
Steve Allen said that DSB's denitrify all the way to nitrogen gas.
<Mmm, can...> In my 30 gallon reef's DSB, I have noticed that small
pockets of air can be seen through the glass all around the edge of the
sand bed. I assume these pockets of air are the end product of
denitrification. <This is possible... but other reactions result in
gasses produced here as well> If they are, it would be significant
to note that the air pockets only occur within the top 1-2" of sand.
Would this support those of the opinion that deeper DSB's offer no
advantage over more shallow beds? <Mmm... no... the gas may be
simply coalescing... floating up to this level> Or is it just as
likely that the visible air pockets are the accumulation of nitrogen gas
that has risen to the top of the bed after being created in the deeper
parts of the bed? <Bingo> Since there is a lack of consensus on
the virtue of DSB's, I thought I would pass my observations along.
Craig <Appreciate this. It may well be that some studies have been
done, published on the make-up of these gas accumulations... not easily
found, indexed in the pet-fish literature, but... there are
college/university libraries with computer-based search systems... Bob
Fenner>
Sand in large setup 10/18/05 Crew- <Craig>
Quick question. What type of commercially available sand would be
acceptable to use for the deeper portion of the DSB? I am not sure I
like the projected cost of putting an all aragonite 6" DSB in a 220
gallon tank. Ouch! Is there a cheaper silica free alternative to
aragonite that I could likely find in bulk? How many inches of a DSB bed
could be of the cheaper variety and how much should be the aragonite?
Please let me know of any other details to be aware of for such a
proposed DSB. If there are FAQ's that already address this, please point
me that way. As always, thank you for your time. <Craig, here is a
link to FAQ's concerning your question.
http://www.google.com/custom?q=south+down+sand&sa=Google+Search&sitesearch=wetwebmedia.com
James (Salty Dog)> Uneven DSB 10/18/05 Hi Adam
<James here today> It's Ai Kun again. I have a question on DSB. My
tank, which is appx. 5 weeks old was started on a 4 inches deep DSB.
After I added my maroon couple two weeks ago, they started 'digging'
around and eventually built two small caves under the live rocks. They
have dug so deep that I could see the glass at one of their spots.
Now I have a very uneven sandbed, a few spots of barely there sandbed
and mostly very deep sand (appx 6-7") at all sides of the tank. Would
this unevenness pose any problem? I tried to smoothen the sandbed, at
least in areas not around their sleeping spots, but they still haven't
got tired of 'digging'. I appreciate any advice/suggestions which you
may have. <Pretty typical of maroons digging and such. I don't see
where this will cause any problems. Read info in this link for more
help.
http://www.wetwebmedia.com/deepsandbeds.htm James (Salty Dog)>
Thank you again. Ai Kun <You're welcome> Question On A
Tiered DSB - 10/05/05 First, I'd like to thank you for all of
the valuable information I've received from reading through your site.
It has been a great help. <<Excellent!>> I am starting a new
tank and want to be able to take advantage of the benefits of a DSB but
don't want to have the DSB in the display tank. Instead, I want to put
the DSB in the sump. <<A refugium would be better, but ok.>>
Here is my question. The stand is relatively tall but the length is
only 48". After placing the equipment and a refugium, there is not much
space for a DSB. <<Mmm...would place it in the refugium.>> I was
wondering if it would be possible to tier the DSB such that it would be
like a layer cake. The first layer would be 6" of sand covered by 4" of
water. Above this layer would be a layer of Plexiglas. On top of the
Plexiglas would be another layer of sand and water. On top of this
would be a final layer of Plexiglas, sand and water. Circulation of the
water across each layer would be provided by small powerheads. Would
this work? <<Possibly... An effective DSB can be as simple as a
5-gallon bucket filled with sand and water flowed over it...so your
design could work, though it sounds a bit "fiddly". I suspect you're
trying to maximize surface area in the DSB, so why not just put it in
the refugium?>> I look forward to your response. Michael
Mud/DSB/Refugium - 09/30/05 Hello and thanks for the great site
and forums. <<Glad you like 'em.>> I could not link to the
forums page to post there, so I thought I would send an email. Thanks
in advance for your help. <<Email is fine.>> I am setting up a
built-in system intended to house a live-rock based reef. My 90G show
tank overflows via a custom tank top into a 55G tank converted to a
three-chamber sump and returns to the main tank via a pump running at
probably 1100gph (Supreme Mag Drive 12). <<Mmm...pretty good
pump...but with head height, probably returning a bit less than you
think.>> This custom setup was originally intended to house an
ecosystem (mud) filter in the central chamber (about 20" x 12"). Over
time and having read various apparently conflicting information, I wound
up investing in some Aragamud from CaribSea instead of Miracle Mud. Do
you know this product, and is it intended to be an alternate to MM or
have I been steered in the wrong direction. <<Honestly, no...I'm not
a user/familiar with either product. Though I think for the application
you describe either will suffice.>> I may be confusing the functions
of a DSB with a mud tank with a refugium, and what I really want to do
is set it up right in the first place. <<Either will do what you
desire. The finer grades of substrate just require less depth to get
the job done.>> My goal is to create a system that allows relatively
low maintenance - i.e., it provides filtration (denitrification and
nutrient export) , it can provide planktonic food, it can reduce the
amount of artificially added supplements needed. <<Oh... so you are
seeking Utopia! <G> >> So is this ideal system a mud tank with just
a thin layer of mud and macroalgae, a DSB with live sand live rock
rubble and macroalgae, or something else? <<My preference is a 6"
DSB of sugar-fine aragonite with Chaetomorpha algae. Though you could
add a layer of "mud" on top of the DSB if you want.>> I have read
through many of your excellent forums, but am still confused. Does a
mud system accomplish denitrification? <<If deep enough, yes.>>
Can a mud system support creatures that could produce the planktonic
food a "refugium" can? <<I think a vegetable refugium excels here.>>
Does a DSB have to be "partially changed out" like Ecosystems recommends
mud systems do? <<Not so much changed out as added
to. Aragonite has a half-life of about 18 mos. so you'll need to add
more every so often.>> Sorry for the disorganized questions. Your
advice is greatly appreciated. I have already invested $$$ in the
system, if I have to invest more to set it up right in the first place,
I am ok with that. <<<<Very good my friend, starting right is key...
EricR>>
Creating a Deeper sand Bed! 9/23/05 Hi
Bob, <Hey there! Scott F. here tonight!> Thanks for your speedy
reply to all my questions in the past. I find this site the most
informative tool on the net (really I do)! <Glad to hear that! We
certainly enjoy bringing it to you!> Anyways, to get going, I've
been looking into making my sandbed a bit deeper. I have a 100g reef
with 150lbs of medium grit LS in the 1.0-2.0mm range at about on
average, 3 inches deep. I made a mistake in adding 20lbs of oolitic LS
to it a couple of months ago, is this harmful? <I don't see any real
problems with that.> The reason why I say, "on average 3 inches" is
because I have this annoying maroon clown that has been raised without
an anemone, she likes to shimmy in the sand causing a major disturbance
in the bed. <An unavoidable Clownfish behavior!> I have a BTA
that she has been hosting in for several months... but old habits are
hard to break. My question is, I would like to achieve a 6" bed. Is my
grit too big? <Well, it is a good size if you're looking at a 4"-6"
sandbed depth, as this slightly larger grain size does require a greater
depth on the average than the finer stuff to foster denitrification.>
Also, if I go "deep", should I get rid of the Clown (very beautiful, if
she wasn't so pretty she'd be out of there) so that the DSB would remain
undisturbed? <A tough call...It is best if the deeper (greater than
the top inch or so) layers are left undisturbed. If you really want to
have an undisturbed DSB, the Clown may need to be removed.> Right
now I'm getting nitrogen gas bubbles in the sediment... should I tamper?
<I wouldn't tamper with it, lest you disturb the very processes that
you're trying to encourage.> Do what you do best, Missy
<Rock on, Missy! I think you're on the right track here! Regards, Scott
F.>
Deep Sand Bed 9/8/05 Hi Guys, I am in the process
of increasing my sand bed. I am currently up to 4 inches down the front
a bit shallower toward the back but more a less 4 inches through out.
<Sounds good!> Should I add more sand or is this fine my tank size
is around 300 litres. I would rather not add if you feel I can get away
with 4 inches for a DSB as my water has been murky for a while. Thanks
Regards, Ziad Limbada <4" is fine for function, but you may have to add
more later as it dissolves and compacts. Best Regards, AdamC.>
Deep Sand Bed part 2 9/13/05 I was thinking that I would rather
get more sand and add some more just to just over 6 inches, while I have
the rock out of the tank I might as well spend a little more time and do
it properly. <I agree that now is the time!> I have spent over 3
weeks doing this process and I am amazed how much the sand has compacted
in this time. I figure that I am almost there, might as well do the
Full Monty even if it takes another 2 weeks. <Kudos on your patience!>
I for one love the look of the deep sand bed. Regards, Ziad Limbada <Me
too! Best Regards. AdamC.>
DSB stirring organisms, yea or
nay ? Leave out the macro-fauna 8/27/05 Hola Crew...
<Que tal Juan?> Getting down to the last few questions as I make the
final decisions on the reef tank I am designing and I just became more
confused than normal <G>. <Keep studying> I *was* planning on
adding a brittle star and a couple of gobies to a 150 gallon (size
keeps changing !) reef tank with a 6" DSB but my research today lead me
to some comments by Dr. Ron S. (whose opinion I certainly respect) where
he seems to indicate nothing larger than infauna should be allowed into
a DSB display tank. My question is; is this a topic being hotly
debated currently ? <Mmm, not as far as I'm aware. RonS's opinion is
widely shared> Should I flip a coin or add the macro fauna and hope
they don't burrow down into the anoxic area of the DSB ?!? <I
wouldn't> Thanks again for all the *great* info at WWM ! JohnAnorexic Anaerobic Bacteria 8/27/05 Dear Crew:
<Paul> Six months ago, I started a 75-gallon reef aquarium with an
inline 29-gallon refuge sump. My plan for natural nitrate reduction
(NNR) was to reduce nitrates to nitrogen gas by cultivating anaerobic
bacteria with a deep sand bed (DSB) and live rock. <Okay> During
the first 5 months of this aquarium, I performed 25% water changes every
week to keep the nitrate levels under control. I want to be able to
reduce my need for water changes with NNR but this does not appear to be
happening. Last month, I decided to wait 4 weeks before changing the
water. While the ammonia and nitrite levels remained near zero, I
found that my nitrate levels had climbed to between 25 and 50 ppm per
the Salifert Nitrate Test. <High> I can add macroalgae to my
refuge sump for nitrate export but I'd rather do that as a last resort.
<Why?> Currently, my refugium is only used for water changes and
houses an Iwaki MD30 pump, a Jager heater, an Ice Cap fan, and a Remora
protein skimmer with carbon filtration. I need your advice on what I
must do to achieve NNR with a DSB and LR in the main tank. The DSB is
4" deep on average and contains sugar-fine oolitic Pure Caribbean
Aragonite from Petroglyph. While it is full of bubbles when viewed
from the side and contains feather dusters, I see no bubbles on the
surface of the DSB. Most of the main tank's volume is occupied by live
rock covered with purple coralline algae and Pachyclavularia violacea
but no observable bubbles. The tank has a generous 10x water flow and
300 watts of DE-halide illumination with fluorescent supplements.
Everything else in the tank seems to be thriving: 1 Condylactis
anemone (left end of tank) 1 Ritteri anemone (right end of tank)
2 Green Fiji Trees Discosoma mushrooms Rhodactis mushrooms
Pachyclavularia violacea Palythoa Assorted button polyps
Halimeda algae 1 Maroon Clown 1 Flame Hawkfish 10 Blue Devil
Damsels 10 Pajama Cardinals Asteroidea sand-sifting starfish
Turbo snails Hermit crab cleanup crew (1) What more must I do to
cultivate the anaerobic bacteria needed to reduce nitrates to nitrogen
gas? <Perhaps add a couple more inches of substrate... I would>
(2) Are there nitrate-reducing anaerobic bacteria cultures that I can
buy? <Mmm, unnecessary> (3) Has anyone succeeded in NNR with a
DSB and LR in the main tank without macroalgae and frequent water
changes? <Yes> My anaerobic bacteria are anorexic! <Heeee!
Do consider removing some/all of the LR from the refugium, adding
macroalgae and a reverse daylight photoperiod there. Bob Fenner>
-Paul. Re: Anorexic Anaerobic Bacteria 8/28/05
Bob, <Paul> I appreciate your reply and wish to pose some
follow-up questions if I may. <Make it so! (Pulls down his tunic)>
You appear to be suggesting that oolitic deep sand beds (DSB) are more
effective in natural nitrate reduction (NNR) than live rocks (LR).
<In general they are> (1) Is this confirmed by published research?
<Mmm, yes... a cursory search of pet-fish literature... by Bob Goeman's,
J. Charley Delbeek, Ron Shimek... maybe Stephen Spotte, Martin Moe will
likely show> (2) How do LR's compare with DSB's in ammonia & nitrite
reduction? <In established settings, about the same... Initially the
rock is more "active", important... per weight, volume... but with time,
the DSB> (3) Does the type of LR matter (Florida versus Fiji)?
<Oh yes... in general, Pacific "rock" is much more "full of holes" than
tropical West Atlantic types... much more useful in terms of "biological
filtration"> Currently, the size of my DSB is restricted only by the
large amount of LR in the aquarium. I can remove live rocks to increase
the size of my DSB. Is this how NNR is accomplished without algal
filtration? <One way> To answer your earlier question, I do not
want to add macroalgae to my refugium because of my bad luck in ordering
it. My order of Gracilaria parvispora from Hawaii arrived with
Aiptasia. My order of Chaetomorpha from the East Coast arrived with
Caulerpa. Unfortunately, there are no local fish stores in my corner of
Colorado. <Mmm, I'd look around... local fish club/s or the Net...
and get some small bit of "pure" culture from a fellow hobbyist... Or
have you tried Inland Aquatics, Terre Haute, IN? Morgan Lidster has a
mighty fine reputation...> My refugium cannot accommodate another
DSB because I designed it to provide an upward current to suspend
macroalgae. I want to make NNR work with LR and DSB in the main tank
and would appreciate your suggestions. <Can be done... though am a
big/ger fan of DSB's being remoted, outside of main/display tanks>
Thanks very much. I very much appreciate your forum and I think that is
greatly advancing marine husbandry. <Wowzah!> Best regards,
Paul. <Bob Fenner> |
|
